PHI BEAT 2 light 20 (65-85kg) CC3 0015551H
$1,935.00
Used PHI BEAT 2 light size 20 colour CC3 in as new condition. Used only by the Flybubble Crew for testing to best advise customers through our Flybubble Match Service.
PHI BEAT 2 light (general info)
Technical data*
| size | 18 | 20 | 22 | 23 | 24 | 26 | 28 | |
|---|---|---|---|---|---|---|---|---|
| standard weight range | kg | 50-75 | 65-85 | 75-95 | 83-103 | 90-110 | 105-130 | 105-155 |
| ext. weight range motor | kg | 50-130 | 65-130 | 75-170 | 83-170 | 90-170 | 105-170 | 105-200 |
| flat area | m² | 20.8 | 23.11 | 25.48 | 26.7 | 27.9 | 30.37 | 32.71 |
| flat aspect ratio | 5.31 | 5.31 | 5.31 | 5.31 | 5.31 | 5.31 | 5.31 | |
| flat span | m | 10.51 | 11.07 | 11.63 | 11.9 | 12.17 | 12.69 | 13.76 |
| projected area | m² | 17.74 | 19.72 | 21.73 | 22.77 | 23.79 | 25.89 | 27.89 |
| projected aspect ratio | 3.88 | 3.88 | 3.88 | 3.88 | 3.88 | 3.88 | 3.88 | |
| projected span | m | 8.29 | 8.74 | 9.18 | 9.4 | 9.61 | 10.02 | 10.4 |
| number of cells | 56 | 56 | 56 | 56 | 56 | 56 | 56 | |
| line length | m | 6.24 | 6.57 | 6.9 | 7.07 | 7.22 | 7.53 | 7.82 |
| maximum chord | m | 2.45 | 2.58 | 2.71 | 2.77 | 2.84 | 2.96 | 3.07 |
| minimum chord | m | 0.66 | 0.7 | 0.73 | 0.75 | 0.77 | 0.8 | 0.83 |
| weight | kg | 3.0 | 3.3 | 3.58 | 3.72 | 3.85 | 4.15 | 4.45 |
| certification (EN/LTF) | B | B | B | B | B | B | B | |
| certification DGAC | ok | ok | ok | ok | ok | ok | i.A. | |
| riser length | mm | 500 | 540 | 540 | 540 | 540 | 540 | 540 |
| speedway | mm | 150 | 150 | 180 | 180 | 180 | 200 | 200 |
* Technical data as provided to us by PHI. Final weights may change a little with production, to be confirmed.
PHI confirmed that the differences between the original BEAT and new BEAT 2 are the internal construction, stabilos and materials. PHI says that from their testing the BEAT 2 keeps the high comfort of the original BEAT, but with significantly improved performance and handling. More info to follow in due course.
Nearly all sizes of BEAT 2 light passed certification now!
Colours
Standard colours: CC1 – blue, CC2 – orange, CC3 – lime.
BEAT 2 and BEAT 2 light have the same colors.
Package
- Wing
- concertina bag
- repair material
BEAT 2 light: THE BEAT GOES ON!
Here the long awaited sucessor of PHI’s bestseller:
- The BEAT 2 light is following the legendary BEAT light as the perfect middle of the wing’s bandwidth.
- The BEAT light strikes the perfect balance of outstanding safety and simplicity on the one hand and performance that will satisfy even an advanced pilot at any time on the other.
- The BEAT 2 light symbolizes the legendary “Golden Ratio” and represents the meaning of our brand PHI like no other of thier wings.
MAECENAS IACULIS
Vestibulum curae torquent diam diam commodo parturient penatibus nunc dui adipiscing convallis bulum parturient suspendisse parturient a.Parturient in parturient scelerisque nibh lectus quam a natoque adipiscing a vestibulum hendrerit et pharetra fames nunc natoque dui.
ADIPISCING CONVALLIS BULUM
- Vestibulum penatibus nunc dui adipiscing convallis bulum parturient suspendisse.
- Abitur parturient praesent lectus quam a natoque adipiscing a vestibulum hendre.
- Diam parturient dictumst parturient scelerisque nibh lectus.
Scelerisque adipiscing bibendum sem vestibulum et in a a a purus lectus faucibus lobortis tincidunt purus lectus nisl class eros.Condimentum a et ullamcorper dictumst mus et tristique elementum nam inceptos hac parturient scelerisque vestibulum amet elit ut volutpat.
Reviews
There are no reviews yet.
