Niviuk Koyot 5 P
$2,175.00
Technical data
| Size | 22 | 24 | 26 | 28 |
|---|---|---|---|---|
| Total weight in flight (kg) | 45-70 | 60-80 | 75-95 | 90-115 |
| Cells | 39 | 39 | 39 | 39 |
| Aspect ratio flat | 4.7 | 4.7 | 4.7 | 4.7 |
| Area flat (m2) | 22 | 24 | 26 | 28 |
| Area projected (m2) | 18.92 | 20.62 | 22.24 | 23.99 |
| Span flat (m) | 10.27 | 10.72 | 11.13 | 11.56 |
| Chord maximum (m) | 2.66 | 2.77 | 2.88 | 3 |
| Lines number (m) | 213 | 223 | 233 | 242 |
| Lines main | 2+1/3/2 | 2+1/3/2 | 2+1/3/2 | 2+1/3/2 |
| Risers number | A+A´/B/C | A+A´/B/C | A+A´/B/C | A+A´/B/C |
| Risers speed bar (mm) | 130 | 130 | 130 | 130 |
| Glider weight (kg) | 3.2* | 3.5* | 3.8* | 4.1* |
| Certification |
EN/LFT A
|
EN/LFT A
|
EN/LFT A
|
EN/LFT A
|
* The total weight of the wing may differ ±2% due to variations in the weight of the fabric supplied by the manufacturers.
Colours
Standard colours: Krater, Tekno
Custom colours: Choose your colours and email us the colour reference with your order. Include a screenshot if you can. Full payment required upfront to confirm your order after which it cannot be canceled.
Package
- Inner bag
- Compression straps
- Risers covers
- Repair kit
Optional extras
- Kargo Backpack (Recommended size 85L – for all sizes)
- NKare Bag 280
Koyot 5 P: Go for adventure
Lower stall speed
The Koyot 5 P has a lower and more intuitive stall speed. The pilot can feel confident using the slow speed range of his glider.
Launching made easy
The progressive and uniform inflation in all wind conditions facilitates an easy take off.
Exceptional safety
The safety of the pilot in all phases of flight is Niviuk`s highest priority. Therefore, the latest Niviuk technologies have been applied to ensure high efficiency and passive safety.
Simple pre-flight preparation
Getting the glider ready for flying is very simple thanks to the simple and minimalist line set.
Stable by nature
The Koyot 5 P has a tendency to stabilise itself after any manoeuvre and has a gradual response to brake inputs. The wing has the capacity to buffer turbulence for increased comfort of the pilot
Instinctive and progressive piloting
At an intermediate level, it is a steadfast and accessible glider to continue progressing steadily. Easy to control and very intuitive to fly, it allows you to gain experience and confidence quickly, while maintaining safety at all times.
Target
Progression
Certified EN A, the Koyot 5 P is a docile, instinctive and safe wing. The pilot´s experience will be enhanced. The pilot will be able to progress gradually and take advantage of the wing´s measured responses to inputs.
Evolution
Try new things in flying thanks to the glider´s excellent performance in thermals, combined with total stability and control.
Hike & fly
The lightness of the Koyot 5 P will allow you to take your first steps in the world of hike & fly to combine your passion for flying with mountaineering. Ascend to the top in comfort, with a glider that is compact, easy to carry and pack. Enjoy different adventures right after completing your training.
Comparative chart of the Koyot 5 P vs Koyot 5 and of the Koyot 5 P vs Koyot 4 P
Niviuk Technologies
Nitinol reinforcements in the canopy
New profiles and canopy arc
New strategic distribution of the line set
The Koyot 5 has a more technical construction of the line set, easier to understand. This makes the wing lighter, easier to manoeuvre and with less drag.
Optimised internal structure
The in-flight load distribution has been improved with a new design combining the use of Nitinol, diagonals with reinforced attachment points.
Leading edge
Its leading edge has a structured design (SLE technology), an extra seam on the span axis (3DL technology) and ideal tensioning without deformations based on the 3DP technology. The use of these technologies preserves the durability of the glider.
