Niviuk Koyot 5
$1,959.00
Technical data
| Size | 22 | 24 | 26 | 28 | 31 |
|---|---|---|---|---|---|
| Total weight in flight (kg) | 45-70 | 60-80 | 75-95 | 90-115 | 110-135 |
| Cells | 39 | 39 | 39 | 39 | 39 |
| Aspect ratio flat | 4.7 | 4.7 | 4.7 | 4.7 | 4.7 |
| Area flat (m2) | 22 | 24 | 26 | 28 | 31 |
| Area projected (m2) | 18.92 | 20.62 | 22.24 | 23.99 | 26.55 |
| Span flat (m) | 10.27 | 10.72 | 11.13 | 11.56 | 12.16 |
| Chord maximum (m) | 2.66 | 2.77 | 2.88 | 3 | 3.15 |
| Lines number (m) | 213 | 223 | 233 | 242 | 255 |
| Lines main | 2+1/3/2 | 2+1/3/2 | 2+1/3/2 | 2+1/3/2 | 2+1/3/2 |
| Risers number | A+A´/B/C | A+A´/B/C | A+A´/B/C | A+A´/B/C | A+A´/B/C |
| Risers speed bar (mm) | 130 | 130 | 130 | 130 | 130 |
| Glider weight (kg) | 4.2 | 4.5 | 4.8 | 5.1 | 5.5 |
| Certification |
EN/LFT A
|
EN/LFT A
|
EN/LFT A
|
EN/LFT A
|
EN/LFT A
|
Colours
Standard colours: Volcano, Matrix, Boreal, Gum
Custom colours: Choose your colours and email us the colour reference with your order. Include a screenshot if you can. Full payment required upfront to confirm your order after which it cannot be canceled.
Package
- Inner bag
- Compression straps
- Risers covers
- Repair kit
Optional extras
- Kargo Backpack (Recommended size 85L for size 22, 150L for bigger sizes)
- NKare Bag 280
Koyot 5: Feel the pilot within you
Lower stall speed
The Koyot 5 has a lower and more intuitive stall speed.
Launching made easy
The progressive and uniform inflation in all wind conditions facilitates an easy take off.
Exceptional safety
The safety of the pilot in all phases of flight is Niviuk`s highest priority. Therefore, the latest Niviuk technologies have been applied to ensure high efficiency and passive safety.
Simple pre-flight preparation
Getting the glider ready for flying is very simple thanks to the simple and minimalist line set.
Stable by nature
The Koyot 5 has a tendency to stabilise itself after any manoeuvre and has a gradual response to brake inputs. The wing has the capacity to buffer turbulence for increased comfort of the pilot
Instinctive and progressive piloting
At an intermediate level, it is a steadfast and accessible glider to continue progressing steadily. Easy to control and very intuitive to fly, it allows you to gain experience and confidence quickly, while maintaining safety at all times.
Target
Instruction, progression, recreational flying
Certified EN A, the Koyot 5 is the ideal companion for progression pilots looking for a fun glider.
The pilot will progress gradually, easily and safely. A glider with a docile character and a progressive level of input response.
Comparative chart of the Koyot 5 vs Koyot 4 and the Koyot 5 vs Koyot 5 P
Niviuk Technologies
Nitinol reinforcements in the canopy
New profiles and canopy arc
New strategic distribution of the line set
The Koyot 5 has a more technical construction of the line set, easier to understand. This makes the wing lighter, easier to manoeuvre and with less drag.
Optimised internal structure
The in-flight load distribution has been improved with a new design combining the use of Nitinol, diagonals with reinforced attachment points.
Leading edge
Its leading edge has a structured design (SLE technology), an extra seam on the span axis (3DL technology) and ideal tensioning without deformations based on the 3DP technology. The use of these technologies preserves the durability of the glider.
| size |
22 ,24 ,26 ,28 ,31 |
|---|---|
| color |
Boreal ,Gum ,Matrix ,Volcano |
